Zing Ear ZE-208D 3 Speed 5-8 Wire Pull Chain Ceiling Fan Switch

$9.95

11 reviews|2 answered questions
  • 90-Day returns
  • 1-Year warranty
  • Fast shipping
  • Designed for 5-8 wire installation
  • Electrical rating: 6A 125VAC – 3A 250VAC
  • UR (UL) recognized
  •  CSA approved
  • Function (Upper wafer): L-2-3, L-3-1, L-1-2, OFF
  • Function (Lower wafer): L-1, L-2, L-3, OFF

SWITCH COMPATIBILITY

Compatible with:

  • Jin You E70469 (dual wafer design only)
  • Santa E70469 (dual wafer design only)
  • Wu Pin LJY-280A (dual wafer design only)

If the existing switch has a single wafer design, then this switch is not compatible

Zing Ear ZE-208D 3 speed 5 wire fan switch - brass
Zing Ear ZE-208D 3 Speed 5-8 Wire Pull Chain Ceiling Fan Switch
$9.95

The Zing ZE-208D activates fan speed by gently tugging the attached ball chain. It provides 3-speed settings and will secure in the fan light kit using the attached screw-in nut.

This 3-speed 5-8 wire capacitor fan switch can handle 6A at 125VAC or 3A at 250VAC.

ZE-208D fits many ceiling fans including Harbor Breeze, Hunter, Hampton Bay, Casablanca, Westinghouse, Forever, and others.

Zing Ear ZE-208D is Compatible with

  • Jin You E70469 (dual wafer design only)
  • Santa E70469 (dual wafer design only)
  • Wu Pin LJY-280A (dual wafer design only)

Zing Ear ZE-208D Specifications

  • Electrical rating: 125V/6A or 250V/3A
  • Function (Upper layer/wafer): L-2-3, L-3-1, L-1-2, OFF
  • Function (Lower layer/wafer): L-1, L-2, L-3, OFF
  • 5-8 Wire capacitor switch
  • Dimensions (approximate): 1.5 x 1.5 x 0.8 inch
  • Material: Plastic Body

Useful Links

  • FAQ page
  • Have a question about this item? Click here to contact us
  • Ceiling fan switch compatibility

11 reviews for Zing Ear ZE-208D 3 Speed 5-8 Wire Pull Chain Ceiling Fan Switch

4.1
Based on 11 reviews
5 star
63
63%
4 star
18
18%
3 star
0%
2 star
0%
1 star
18
18%
1-10 of 11 reviews
  1. MF
    Michael Fox
    Verified Purchase

    It worked great, and the directions which came with it were better than any video I had seen.

    (0) (0)
  2. SF
    Stanley Fornander
    Verified Purchase

    switch works in the fan but when wired like the old one only has two speeds,

    (0) (0)
  3. MD
    Michael Dupre
    Verified Purchase

    switch was as descibed, perfect match, works find

    (0) (0)
  4. JW
    Jonathan Wroble
    Verified Purchase

    The replacement works great (all 3 speeds). Thanks for the general info, and wiring info on your website. Also thanks for the fast shipping/processing.

    (0) (0)
  5. LS
    LOUIIS SHOUB
    Verified Purchase

    Zing Ear ZE-208D 3 Speed 5-8 Wire Pull Chain Ceiling Fan Switch

    (0) (0)
  6. FM
    fernando Moreno
    Verified Purchase

    I could not make this switch work. I connected exactly as the old one was hooked up, same model.
    Ended up putting my old one back on with a new capacitor. Fan works now with old switch. Would not work with new switch.

    (0) (0)
  7. JU
    john U
    Reviewer

    I am still waiting on my part

    (0) (0)
  8. JB
    Jennifer Bernard
    Reviewer

    Super quick service
    Perfect replacement

    (0) (0)
  9. FS
    Frederick Smith
    Reviewer

    I have a fifty year old 52″ hunter fan with a five condiuctor switch and I had hoped to use the one I received from you but I haven’t a clue on how to stick wires info five of the eight holes because there isn’t any wiring instruction furnished with said switch to give me a clue as to which of the eight holes I need to use to tie in the three speeds and starting capacitor.

    (0) (0)
  10. C
    Customer
    Reviewer

    Ordered this ceiling fan speed switch and a touch lamp switch, both seem to be as good if not better than the original. Very pleased.

    (0) (0)
Add a review
Zing Ear ZE-208D 3 Speed 5-8 Wire Pull Chain Ceiling Fan Switch Zing Ear ZE-208D 3 Speed 5-8 Wire Pull Chain Ceiling Fan Switch
Rating*
0/5
* Rating is required
Your review
* Review is required
Name
* Name is required
Add photos or video to your review

Q & A

Ask a question
Zing Ear ZE-208D 3 Speed 5-8 Wire Pull Chain Ceiling Fan Switch Zing Ear ZE-208D 3 Speed 5-8 Wire Pull Chain Ceiling Fan Switch
Your question
* Question is required
Name
* Name is required
I have a ceiling fan that needs a replacement switch for e70469. Do you know what switch will replace this one? Thank you CB asked on July 4, 2025

Hi,

Thanks for your question!

Please refer to the listing description, where we’ve included details about all compatible switch models, including replacements for E70469 (if applicable). This will help you determine if the switch we offer is the right fit for your ceiling fan.

Thank you

 CeilingFanSwitch.com answered on July 4, 2025
(0) (0)
Add an answer
Your answer
* Answer is required
Name
* Name is required
I am replacing my 3 speed chain pull ceiling fan switch. (It is a Sears Ceiling Fan, No Light ) The problem is I bought 2 switches, one with 4 connections and one with 4 over 4 Connections L-1-2-3. My problem is I have 5 wires Red-1, Brown-2, Grey- 3, Yellow-4, Black-L. I have one wire (Yellow) I'm not sure where it should go. Can you help me with this question? bob paris asked on March 2, 2024

Hi Bob,

Please check this link for more details on switch compatibility: https://www.ceilingfanswitch.com/ceiling-fan-switch-guide/

Thank you

 CeilingFanSwitch.com answered on March 3, 2024
